How To Measure The Sliding Door Track?

Sliding door. In addition to providing sealing and dust-proof functions for wardrobes and cloakrooms, it can also be used in kitchens, balconies, bathrooms, etc., to achieve good space isolation and increase privacy.


There are always some problems in the use and installation of sliding doors. Several common problems and solutions are summarized. As follows:

The sliding door feels heavy and difficult to move. How to deal with it?
1. The lifting rail does not match with the lifting wheel, and supporting products can be selected;
2. If the lifting rail is deformed during installation, replace the lifting rail;
3. If the lifting rail is not flat, readjust the horizontal surface of the lifting rail;
4. If the bottom surface of the door contacts the ground, or the positioner and the door are not on the vertical line, adjust the door height or move the positioner position;
5. If the bearing of the hanging wheel is poor or there is no bearing at all, or the outer layer is too soft, replace the hanging wheel;
6. There are high and low adjustment doors around the door.


How to measure the size of glass sliding door?
When measuring the size of glass sliding door, mainly measure the height and width.
The height and size of the door is the height of the sliding door first, then the depth of the glass opening is added to the sliding door, and then 0.1cm is subtracted. This is the exact size of the height of the glass sliding door.
For example, if the height of the sliding door is 45 cm and the depth of the upper glass groove is 0.8 cm, the height of the glass sliding door should be 45.7 cm.Width and dimension: as long as the position (width) of the sliding door is measured, then the dimension is divided into two, and each side is added with 3cm, which is the width of the glass sliding door.

For example, if the sliding door is 100 cm apart, the width of the two glass sliding doors is 53 cm.
Summary: the formula is: height = height of sliding door + groove depth of glass - 0.1cm; Width = width of sliding door / 2 + 3cm.The sliding rail of doors and windows is a guide rail with groove or curve for sliding doors and windows. It is often equipped with ball bearings. In modern home life, the selection of door and window sliding rails is learned. If the sliding rails of doors and windows are selected correctly, the service life of the doors and windows can be increased correspondingly, and the safety performance will be improved a lot. The following information points for purchasing doors and windows will be introduced one by one.


Door and window sliding rail material


The sliding rails of doors and windows in the market are made of different materials. Most of the slide rails are made of alloy, and some are made of copper. If it is alloy, it can be divided into ordinary type and thickened type. These two types are determined according to the texture of the applicable door or window. The former is suitable for doors and windows with small volume and light weight; The latter is applicable to heavy doors and windows to ensure safety.


Price reflects quality


The price difference of the door and window slide rail reflects its quality, which is mainly affected by the workmanship and material of the slide rail and pulley. In the market, the price of the door and window slide rails is a few yuan / linear meter, the middle price is more than ten yuan / linear meter, and the high-end price is 30 or 40 yuan / linear meter.
The stronger the pulley, the higher the price. There is a type of door and window track in the market - three fold track. The difference in price also reflects the difference in quality. Because the three fold rails are expanded and contracted by rolling the balls between the rails, the tightness and evenness of the contact between the balls and the rails are very important. The first high-grade three fold rail is about 100 yuan, the ball rolling is uniform, and there is no unnecessary noise, which is 6-7 times of the low-grade price.

Matching pulley is very important


The heavy pulley of the door and window slide rail is a non negligible accessory. A high-quality pulley can help doors and windows push and pull better. So, how should we look at the quality of the pulley? According to the quality of the outer wheel and bearing of the pulley.
The outer wheels are mostly nylon fiber or all copper. Compared with the two, the nylon fiber pulley has no sound during the pulling process, but its abrasion resistance is insufficient; Although the copper is relatively strong, there is a sound when it is pulled.


The materials of bearings are also very different. Pulleys made of imported stainless steel materials are generally of good quality. They are relatively tight when installed. They feel good when sliding and have no noise.
Some high-grade pulleys can also adjust the height to make the door and window tracks more closely connected. There are also small pulleys at the bottom of doors and windows. Good pulleys can promote pulling. In the market, there are some pulleys equipped with anti jump devices, which can greatly improve the safety performance of door and window sliding rails.
